DM-100S Agile Demodulator

Convert any RFsignal back to AV signal for recording or monitoring

DM-100S is a professional designed Demodulator to work with modulator. Demodulate any RF signal back to A/V signal within 50~860MHz. DM-100S provides not only excellent quality but also convenient installation..

  • Easy to adjust channel

  • Channel memory after power re-supply

  • Digital LED Channel Display

  • Suitable for CCTV, CATV

  • Mounted on 19" rackmount

  • Frequency range : 50 ~ 860 MHz

  • Improve the transmission quality without noise / interference

Display ModeDigital LED Channel Display
Video SignalNTSC, PAL B/G, PAL I and PAL D/K
Input Frequency Range50-860MHZ
Input Level Range-5 ~ +30 dbmv
Video Output1Vp-p +/- 0.2p-p(75Ω)
Audio Output0.755Vp-p +/-0.2p-p(600Ω)
Noise Figure10 dB maximum
ConnectorTwo Audio RCA input, one Video RCA input, one RF input
Channel Memory Last channel memory
Power RequirementDC 7.5~12 V / 300 mA
Power Consumption1.5 Watts
Dimension161mm(L) x 118mm(W) x 32mm(H)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
