LSP-600 Lightning Surge Protector

Lightning protector for outdoor wireless application

LSP-600 Lighting surge protector is a wide-band up to 6GHz. Its low cost and high performance are ideal for 2.4/5GHz wireless applications.

  • Wide-band operation 0-6 GHz

  • Compatible with 2.4/5 GHz device

  • Lightning protector for outdoor wireless application

  • N-male to N-female connector type

Frequency Range0~6GHz
Insertion Loss2.4GHz : 0.5dB / 5GHz : 0.2dB
V.S.W.R.< 1.5
Independence50 ohm
Max. with Standing Current10KA @8/20uS
ConnectorN female - N male

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
