GR-2421 2.4GHz Grid Antenna 21dBi
2.4G Directional Antenna for Transmitter or Receiver
This is professional & directional antenna suitable for outdoor application.
|
Model | GR-2421 |
Type | Grid Antenna |
Frequency | 2.4~2.5 GHz |
Gain | 21 dBi |
Connector | N Type Female |
Polarization | Linear |
Wave Impedance | 50 ohm +/- 5 ohm |
Radome Mater | Aluminum and ABS |
Power Handling | 20W Max |
Dimension | 600mm(L) x 435mm(W) x 270mm(H) |
Weight | 1.05kg |
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice. |
