TR-2020 2.4GHz Digital Wireless AV Sender

Digital signal transmission avoids any interference from other wireless devices

The digital AV sender is designed at 2.4GHz via hopping mode. Different from traditional analog solution, this wireless device provides security ID code to protect your privacy and avoid any interference from other wireless devices. CCTV camera, Satellite receiver, Set-Top-Box, DVD and any other AV device is available.

  • Interference Free

  • Auto pairing with ID

  • High resolution ( D1 )

  • Real time wireless Vido and Audio

  • Worldwide NTSC / PAL system available

  • Simple installation and setup

  • Long distance transmission

  • Suitable for surveillance, AV transmission

Frequency Range2400~2483MHz
Channel SwitchFHSS mode
Modulation16QAM, QPSK, BPSK
Video Input Signal Level1Vp-p @75ohm
Video/Audio connectorBNC connector
Power SupplyDC 9 V / 500mA
Dimension135mm(L) x 95mm(W) x 30mm(H)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
