RF-2W 2-Way RF Splitter

1 in 2 out / 2 in 1 out for RF signals

RF-2W is a broadband RF splitter with professional quality. For CCTV system, it also used as RF combiner to combine all RF signals. The differences from others are low-loss and no interference.

Excellent quality with full frequency range 5 - 1000MHz
Hight isolation
Low Insertion Loss / no interference
Excellent performance for RF signals
Balanced (Equal Loss on All Ports) Design
Made in Taiwan

Model	RF-2W
Insertion Loss (dB)	3
Isolation (dB)	24
Connectors (all ports)	"F" Female
Impedance (all ports)	75Ω
Frequency Range	5-1000 MHz
Dimension	56mm(L) x 50mm(W) x 22mm(H)
Weight	60g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
