Weihai Systems -- 2.4GHz Dish Antenna 13dBi

DH-2413 2.4GHz Dish Antenna 13dBi

2.4G Dish Antenna for Transmitter or Receiver

DH-2413 is professional & directional antenna in economical price. Suitable for outdoor applications.

Support A/V wireless 2.4GHz transmitter (TR-2020,TR-1020,TR-1020B,TR-500,TR-100,WS-240 )
Suitable for 2.4 GHz wireless AP, wireless router
High Gain 13 dBi to get excellent quality
Extension cable with different connectors to match any wireless device
Easy Installation

Model	DH-2413
Type	Dish Antenna
Frequency	2.4~2.5 GHz
Gain	13 dBi
Connector	SMA Female
Beam Width H	13 degrees
Wave Impedance	50 ohm +/- 5 ohm
Dimension	300mm(L) x 300mm(W) x 68mm(H)
Weight	350g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
