TR-5886 5.8GHz AHD Wireless Kit

Penetrating Walls , Floors , Ceilings , Interference Free.

TR-5886 is a powerful 5.8 GHz wireless AHD video sender. Transmit high quality video for AHD CCTV camera. At 5.8GHz frequency band to keep the interference from 2.4GHz band. With dipole antennas, providing excellent transmission long distance. For longer distance, you can change to optional & more powerful Antennas.

  • Worldwide 5.8GHz ISM Band

  • No Interference from Crowded 2.4GHz Band

  • Transmit AHD Video Signal by Wireless

  • Compatible with both NTSC/ PAL

  • Digital LED Channel Display

  • 7-Channel Selectable

  • Easy Installation and Setup

  • Antenna Replaceable

Model TR-5886
Video SignalAHD-M, CVBS ( NTSC and PAL )
Frequency Range5725 ~ 5875 MHz
Channel7-Channel Selectable
Display ModeDigital LED Channel Display
Antenna TypeSMA (F)
IR Remoteoption
Power Supply DC 12V/800mA
Dimension118mm(L) x 86mm(W) x 32mm(H)
Power Supply DC 9V/400mA
Dimension118mm(L) x 86mm(W) x 32mm(H)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
