OM-2415 2.4GHz Omni Antenna 15dBi

2.4G Wireless Outdoor OMNI Antenna for Base Station with Hi-Gain

OM-2415 is a highly efficient omni antenna which covering 360 degrees. Pole mounting available for outdoor application such as Wifi.


  • Suitable for A/V wireless transmitter/receiver (TR-2020,TR-1020,TR-1020B,TR-500,TR-100,WS-240 )

  • Support 2.4 GHz wireless AP, wireless router

  • High Gain 15 dBi to get excellent quality

  • Extension cable with different connectors to match any wireless device

  • Easy Installation

ModelOM-2415
TypeOmni Antenna
Frequency2.4~2.5 GHz
Gain15 dBi
ConnectorN Female
Beam Width H360 degree
Wave Impedance50 ohm +/- 5 ohm
Dimension1060mm(L) x 38mm(W) x 38mm(H)
Weight500g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
