CPS-200D 2 Cameras + RS485 Transmission

Two Videos with RS485 Data Transmission

This device is an excellent transmission kit to transmit 2 videos with RS485 data via one coaxial cable. No matter you want to install 2 new PTZ cameras or replacing fixed cameras to PTZ cameras, only one pair over existing cable is done. It takes seconds to connect controlling wires to PTZ controller. Simple and easy for you to install 2 PTZ cameras.


  • Two videos and RS485 over a coaxial cable

  • Support all PTZ cameras

  • Long distance transmission

  • Easy installation to save much cost of cable, labor and time

ModelCPS-200D
Video Channel2
RS485 Baud RateAuto
RS485 ProtocolAuto
Temperature Range-10°C~60°C
Transmitter
Video Input1.0Vp-p (75 ohm)
Data LEDGreen
RS485 ModeSimplex (Receiver)
Power Consumption2.5W
Power RequirementsDC9~12V / 210mA
Dimension102mm(L) x 110mm(W) x 30mm(H)
Weight280g
Receiver
Video Output1.0Vp-p +/- 0.2Vp-p (75 ohm)
Data LEDRed
RS485 ModeSimplex (Transmitter)
Power Consumption1.7W
Power RequirementsDC9~12V / 140mA
Dimension102mm(L) x 110mm(W) x 30mm(H)
Weight280g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
