YG-2409 2.4GHz Yagi Antenna 9dBi
2.4G Directional Antenna for Transmitter or Receiver
The YG-2409 Yagi Antenna is a 9 dBi directional wireless antenna for the 2.4 GHz band. It is used in 2.4G wirelee LAN.
|
Type | Yagi Antenna |
Frequency | 2.4~2.5 GHz |
Gain | 9 dBi |
Connector | N Female |
Wave Impedance | 50 ohm +/- 5 ohm |
Polarization | Horizontal |
Dimension | 330mm(L) x 99mm(W) x 33mm(H) |
Weight | 162g |
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice. |
