CPS-100AHD 1CH long-distance transmission

Anti-noise and avoid interference

CPS-100AHD is a long-distance transmission unit for one CCTV camera. It provides excellent quality in against-noise and good isolation to maintain high performance of Video. In some interfered projects such as Elevator, Factory, Engine room, motor machine, ......etc. CPS-100AHD can solve the Video interference easily.

Long distance AHD transmission Excellent transmission without interference Easy installation Saving much cost of cable, labor and time

Model	CPS-100AHD
Channels	1 Channel
Video Resolution	AHD-H 1080P / AHD-M 720P / 960H / CVBS
Temperature Range	-10°C~60°C
Transmitter
Video Input	1.0Vp-p (75 ohm)
Power LED	Red LED
Power Consumption	0.6 W
Power Requirements	DC9~12V / 50mA
Dimension	115mm(L) x 76mm(W) x 31mm(H)
Weight	165g
Receiver
Video Output	1.0Vp-p +/- 0.2Vp-p (75 ohm)
Power LED	Green LED
Power Consumption	1.6 W
Power Requirements	DC9~12V / 130mA
Dimension	115mm(L) x 76mm(W) x 31mm(H)
Weight	175g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
