TR-5850DK 5.8G outdoor wireless kit

Weatherproof enclosure with high gain antenna for outdoor wireless transmission

This wireless video transceiver is specially designed for outdoor wireless CCTV installation. Built-in high gain antenna with all-in-one compact weatherproof enclosure, providing excellent video quality transmitted without any delay. Suitable for parking lot, playground, swimming pool, ranch, farm, ...... etc.


  • Worldwide NTSC/PAL system applicable

  • 7 Channels for selection

  • High resolution video transmission

  • Real time video & audio

  • Easy to install and operate

  • Weatherproof enclosure

  • High gain antenna

Model TR-5850DK
Output Power 500mW
Frequency Range5725 ~ 5875 MHz
Channel7-Channel Selectable
Display ModeDigital LED Channel Display
ModulationFM-FM
Antenna14dBi Panel antenna
Transmitter
Power Supply DC 6V/800mA
Dimension250mm(L) x 185mm(W) x 60mm(H)
Weight530g
Receiver
Power Supply DC 9V/400mA
Dimension250mm(L) x 185mm(W) x 60mm(H)
Weight510g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
