RF-3W 3-Way RF Splitter
3 in 1 out / 1 in 3 out for RF signals
RF-3W is a broadband RF splitter with professional quality. For CCTV system, it also used as RF combiner to combine all RF signals. The differences from others are low-loss and no interference.
|
Model | RF-3W |
Insertion Loss (dB) | 6 |
Isolation (dB) | 24 |
Connectors (all ports) | "F" Female |
Impedance (all ports) | 75Ω |
Frequency Range | 5-1000 MHz |
Dimension | 71mm(L) x 50mm(W) x 20mm(H) |
Weight | 84g |
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice. |
