Weihai Systems -- 2.4GHz Panel Antenna 9dBi

PA-2409 2.4GHz Panel Antenna 9dBi

2.4G Directional Antenna for Transmitter or Receiver

The PA-2409 Panel Antenna is a directional wireless antenna for the 2.4 GHz band.

Suitable for A/V wireless transmitter / receiver (TR-2020,TR-1020,TR-1020B,TR-500,TR-100,WS-240 )
Support 2.4 GHz wireless AP, wireless router
High-gain 9 dBi to get excellent quality
Easy Installation

Model	PA-2409
Type	Panel Antenna
Frequency	2.4~2.5 GHz
Gain	9 dBi
Connector	N Female
Wave Impedance	50 ohm +/- 5 ohm
Polarization	Vertical
Dimension	110mm(L) x 95mm(W) x 28mm(H)
Weight	275g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
