CPS-300AHD 3CH long-distance transmission

Anti-noise and avoid interference

CPS-300AHD are specially designed to transmit multi-video by single coaxial cable. CPS-300AHD is a long distance transmission unit for 3 AHD cameras. It provides excellent quality in against-noise and good isolation for avoiding interference from other devices.


  • Send 3 AHD video signals for long distance transmission

  • Excellent transmission without interference

  • Easy installation

  • Saving much cost of cable, labor and time

ModelCPS-300AHD
Channels3 Channels
Video ResolutionAHD-H 1080P / AHD-M 720P / 960H / CVBS
Temperature Range-10°C~60°C
Transmitter
Video Input1.0Vp-p (75 ohm)
Power LEDGreen LED
Power Consumption3 W
Power RequirementsDC9~12V / 250mA
Dimension170mm(L) x 112mm(W) x 32mm(H)
Weight485g
Receiver
Video Output1.0Vp-p +/- 0.2Vp-p (75 ohm)
Power LEDGreen LED
Power Requirements2.4 W
Power ConsumptionDC9~12V / 200mA
Dimension170mm(L) x 112mm(W) x 32mm(H)
Weight485g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
