AMP-32 Broadband RF signal Amplifier

Amplify your RF signals for multiple distribution

For CCTV/CATV/Digital TV systems, AMP-32 improves the quality of whole system in solving the problems of noise, interference and weakness after distribution. Providing 32 dB value with both dB output power and slope adjustment for master antenna, to prolong the transmission distance of CATV system / CCTV system / Digital TV.

  • Aluminum chassis provides excellent heat dissipation

  • Hybrid module design

  • Built-in Variable Gain and Slope controls

  • Input Frequency: 50~860MHz

  • Maximum Gain: 32db

  • Input & Output Test Point: -20dB Gain / Slope Control range: 0 ~ -20db continuously adjustable

  • Connector: Input / Output 75Ω impedance

  • Made in Taiwan

Input Frequency 50~860MHz
Maximum Gain32db
Input & Output Impedance75Ω
Input & Output Test Point-20dB
Gain / Slope Control range0 ~ -20db continuously adjustable
ConnectorInput / Output 75Ω impedance
Power RequirementAC 110 ± 10% or AC 220 ± 10% VAC
Power Consumption10 Watts
Dimension200mm(L) x 120mm(W) x 52mm(H)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
