CPS-200 Long-distance transmission
Anti-noise and avoid interference up to 1000 meters
 |
|
CPS-200 is a long distance transmission unit for one CCTV camera. It provides excellent quality in against-noise and good isolation to maintain high performance of video.
 |
|
| Model | CPS-200 |
| Channels | 2 Channels |
| Video Signal | NTSC / PAL both available |
| Temperature Range | -10°C~60°C |
| Transmitter | |
| Video Input | 1.0Vp-p (75 ohm) |
| Power LED | Green LED |
| Power Consumption | 2.1 W |
| Power Requirements | DC9~12V / 170mA |
| Dimension | 102mm(L) x 110mm(W) x 30mm(H) |
| Weight | 275g |
| Receiver | |
| Video Output | 1.0Vp-p +/- 0.2Vp-p (75 ohm) |
| Power LED | Green LED |
| Power Requirements | 1.6 W |
| Power Consumption | DC9~12V / 130mA |
| Dimension | 102mm(L) x 110mm(W) x 30mm(H) |
| Weight | 270g |
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice. | |
