RF-6W 6-Way RF Splitter

6 in 1 out / 1 in 6 out for RF signals

RF-6W is a broadband RF splitter with professional quality. For CCTV system, it also used as RF combiner to combine all RF signals. The differences from others are low-loss and no interference.


  • Excellent quality with full frequency range 5 - 1000MHz

  • Hight isolation

  • Low Insertion Loss / no interference

  • Excellent performance for RF signals

  • Balanced (Equal Loss on All Ports) Design

ModelRF-6W
Insertion Loss (dB)9.8
Isolation (dB) 24
Connectors (all ports) "F" Female
Impedance (all ports) 75Ω
Frequency Range 5-1000 MHz
Dimension127mm(L) x 58mm(W) x 40mm(H)
Weight188g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
