CPS-100 Long-distance transmission (1CH)

Anti-noise and avoid interference up to 1200 meters

CPS-100 is a long-distance transmission unit for one CCTV camera. It provides excellent quality in against-noise and good isolation to maintain high performance of Video. In some interfered projects such as Elevator, Factory, Engine room, motor machine, ......etc. CPS-100 can solve the Video interference easily.


  • Long distance transmission

  • Excellent transmission without interference

  • Easy installation

  • Saving much cost of cable, labor and time

ModelCPS-100
Channels1 Channels
Video SignalNTSC / PAL both available
Temperature Range-10°C~60°C
Transmitter
Video Input1.0Vp-p (75 ohm)
Power LEDRed LED
Power Consumption0.6 W
Power RequirementsDC9~12V / 50mA
Dimension115mm(L) x 76mm(W) x 31mm(H)
Weight165g
Receiver
Video Output1.0Vp-p +/- 0.2Vp-p (75 ohm)
Power LEDGreen LED
Power Consumption1.6 W
Power RequirementsDC9~12V / 130mA
Dimension115mm(L) x 76mm(W) x 31mm(H)
Weight175g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
