OM-5812 5.8GHz Omni Antenna 12dBi
5.8G Antenna for Transmitter or Receiver
 |
|
This is high efficient Omni antenna which covering 360 degrees. Suitablee for outdoor application.
 |
|
| Model | OM-5812 |
| Type | Omni Antenna |
| Frequency | 5.725~5.875GHz |
| Gain | 12dBi |
| Wave Impedance | 50ohm+/-5ohm |
| Connector | N Type Female |
| Polarization | Linear |
| Power Handling | 10W max |
| Dimension | 420mm(L) x 35mm(W) x 35mm(H) |
| Weight | 430g |
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice. | |
