CPS-400 Long-distance transmission

Anti-noise and avoid interference up to 800 meters

CPS-400 are specially designed to transmit multi-video by single coaxial cable. CPS-400 is a long distance transmission unit for four CCTV cameras. It provides excellent quality in against-noise and good isolation for avoiding interference from other devices.

  • One pair send 4 video signals for long distance transmission

  • Excellent transmission without interference

  • Easy installation

  • Saving much cost of cable, labor and time

Channels4 Channels
Video SignalNTSC / PAL both available
Temperature Range-10°C~60°C
Video Input1.0Vp-p (75 ohm)
Power LEDGreen LED
Power Consumption3.9 W
Power RequirementsDC9~12V / 320mA
Dimension170mm(L) x 112mm(W) x 32mm(H)
Video Output1.0Vp-p +/- 0.2Vp-p (75 ohm)
Power LEDGreen LED
Power Requirements2.9 W
Power ConsumptionDC9~12V / 240mA
Dimension170mm(L) x 112mm(W) x 32mm(H)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
