CPS-201 3 cameras by one cable

Adding new camera without any new cable. Just one pair for 3 cameras by existing cable.

CPS-201 are specially designed to transmit multi-video by single coaxial cable. Using existing one or designing one route to plus new cameras, transmit long-distance, against noise and interference. Even couple cameras are done by one pair of CPS-201. I believe it will be amazing to you !


  • One pair for 3 cameras by one cable

  • Videos are excellent without interference

  • Flexible application to match the locations of cameras

  • Easy installation to save much cost of cable, labor and time

ModelCPS-201
Channels3 Channels
Video SignalNTSC / PAL both available
Temperature Range-10°C~60°C
Transmitter
Video Input1.0Vp-p (75 Ω)
Power LEDGreen LED
Power Consumption2.1 W
Power RequirementsDC9~12V / 170mA
Dimension102mm(L) x 110mm(W) x 30mm(H)
Weight280g
Receiver
Video Output1.0Vp-p ± 0.2Vp-p (75 ohm)
Power LEDGreen LED
Power Consumption1.6 W
Power RequirementsDC9~12V / 130mA
Dimension102mm(L) x 110mm(W) x 30mm(H)
Weight275g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
