MD-500 Agile Modulator

Convert any AV signal into RF signal as a TV channel frequency

The MD-500 Agile Modulator is a DSB ( Double-Sideband ) modulator to modulate any analog A/V signal to RF ( Radio Frequency ) signal. The same concept as TV channels, one new RF signal is one new TV channel. You can combine CCTV camera, Satellite Receiver, DVD Player or any A/V device into your TV / CCTV system.

  • Push to adjust channel

  • Output 100 dB value

  • Channel memory after power re-supply

  • Suitable for CCTV, CATV, Satellite TV

  • Mounted on 19" Rackmount

Display ModeDigital LED Channel Display
Video SignalNTSC, PAL B/G, PAL I and PAL D/K
Video Input1.0Vp-p.for87.5% modulation
Audio InputPre-emphasis 75us
RF Output Strength100 +/- 5 dbuv
ConnectorOne audio input, one video input, one -20 db test point, one RF out, all standard F connectors
Power RequirementDC7.5~ 12 V / 100 mA
Power Consumption1.5 Watts
Dimension118mm(L) x 86mm(W) x 32mm(H)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
