RF-1004 Cable transmitter/ cable receiver

Combine all videos and audios into one coaxial cable

Model Channels Distance
RF-1004 4CH RG6 - 500m RG-11 - 800m
RF-1008 8CH RG6 - 400m RG-11 - 600m
RF-1016 16CH RG6 - 200m RG-11 - 300m
For longer distance, by additional RF Amplifier



RF-1004 series cable Transmission is designed for CCTV system to transmit all 4 cameras by only one coaxial cable. It saves not only cable, time and labor cost but earns the excellent performance for CCTV itself. Attractively, it is also an effective way to do extending cameras. Saving lots of cable installation and drilling holes all over building.


  • Multi-distribution for many monitors

  • Excellent quality for videos and audios

  • Easy cabling and cost effecitve

  • Save spaces, time and money

  • By existing cable is done

  • Suitable for CCTV surveillance

  • Mounted on 19" rackmount

ModelRF-1004
Channel4CH
Display ModeDigital LED channel display
Video SignalNTSC / PAL both available
Memory FunctionLast channel memory
Power RequirementDC7.5~12V / 1.2A
Transmitter
Video Input1.0Vp-p
Audio InputPer-emphasis 75us
Weight2.15kg
Dimension330mm(L) x 95mm(W) x 90mm(H)
Receiver
Video Output1Vp-p ± 0.2p-p(75 ohm)
Audio Output0.755Vp-p ±0.2p-p(600 ohm)
Weight3kg
Dimension330mm(L) x 155mm(W) x 90mm(H)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
