CPS-301 4 cameras by one cable

Adding new camera without any new cable. Just one pair for 4 cameras by existing cable.

CPS-301 are specially designed to transmit multi-video by single coaxial cable. Using existing one or designing one route to plus new cameras, transmit long-distance and against noise without interference. 4 cameras are done by one pair of CPS-301. I believe it will be amazing to you !

  • One pair for 4 cameras by one cable

  • Videos are excellent without interference

  • Flexible application to match the locations of cameras

  • Easy installation to save much cost of cable, labor and time

Channels4 Channels
Video SignalNTSC / PAL both available
Temperature Range-10°C~60°C
Video Input1.0Vp-p (75 Ω)
Power LEDGreen LED
Power Consumption3 W
Power RequirementsDC9~12V / 250mA
Dimension170mm(L) x 112mm(W) x 32mm(H)
Video Output1.0Vp-p ± 0.2Vp-p (75 ohm)
Power LEDGreen LED
Power Consumption2.4W
Power RequirementsDC9~12V / 200mA
Dimension170mm(L) x 112mm(W) x 32mm(H)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
