CPS-100HD 1CH long-distance transmission

Anti-noise and avoid interference

CPS-100HD is a long-distance transmission unit for one CCTV camera. It provides excellent quality in against-noise and good isolation to maintain high performance of Video. In some interfered projects such as Elevator, Factory, Engine room, motor machine, ......etc. CPS-100HD can solve the Video.

  • Long distance AHD & TVI transmission

  • Excellent transmission without interference

  • Easy installation

  • Saving much cost of cable, labor and time

Channels1 Channel
SignalsAHD, TVI & CVBS
Temperature Range-10°C~60°C
Video Input1.0Vp-p (75 Ω)
Power LEDGreen LED
Power Consumption0.8 W
Power RequirementsDC 9~12V / 60mA
Dimensions78 x 31 x 84 (unit : mm)
Video Output1.0Vp-p ± 0.2Vp-p (75 ohm)
Power LEDGreen LED
Power Consumption0.9 W
Power RequirementsDC 9~12V / 70mA
Dimensions78 x 31 x 84 (unit : mm)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
