OM-5809S 5.8GHz Omni Antenna 9dBi

5.8G Wireless Outdoor OMNI Antenna for Base Station with Hi-Gain

OM-5809S is a highly efficient omni antenna which covering 360 degrees. Pole mounting available for outdoor application such as Wifi.

Suitable for A/V wireless transmitter/receiver
Support 5.8 GHz wireless AP, wireless router
High Gain 9 dBi to get excellent quality
Extension cable with different connectors to match any wireless device
Easy Installation

Model	OM-5809S
Type	Omni Antenna
Frequency	5.725~5.875GHz
Gain	9 dBi
Connector	SMA male
Beam Width H	360 degree
Wave Impedance	50 ohm +/- 5 ohm
Dimension	370mm(L) x 10mm(W) x 10mm(H)
Weight	75g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
