TR-1020B 2.4GHz Wireless AV Sender

Long distance video transmission with Excellent Penetration

Long Distance model of 2.4GHz audio/video sender. Transmit crystal & clear video and stereo audio signal from CCTV camera / satellite TV / digital TV set top box / DVD player. Available for any AV device and keeping it without interference from other 2.4GHz band. With external & directional dipole antennas to provide an excellent transmission up to 1000 meters (clear line of sight). For longer distance, you can change to optional & powerful Antennas. Unique Frequency to avoid Interference from other 2.4GHz Band.


  • 10-Channel Selectable

  • Antenna Replaceable

  • Easy Installation for CCTV System

  • Transmit any Audio/ Video signal

  • PAL/ NTSC Available

  • Digital LED Channel Display

  • Unique Frequencies to Avoid Interference from other 2.4GHz Band

  • Standard Output / High Power Output

  • Made in Taiwan

ModelTR-1020B
Power OutputStandard 10mW / High Power 1W
Frequency Range2400~2483MHz
Channel10-Channel Selectable
Display ModeDigital LED Channel Display
Video-Audio Modulation/Demodulation TypeFM-FM
Antenna TypeSMA (F)
Transmitter
Power Supply DC 12 V / 1 A
Dimension110mm(L) x 102mm(W) x 30mm(H)
Weight250g
Receiver
Power Supply DC 9 ~12V / 300mA
Dimension110mm(L) x 102mm(W) x 30mm(H)
Weight255g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
