LSP-600 突波保護器

保護裝置避免雷擊和其他電力突波

突波保護器可以保護網路避免雷擊和其他電力突波。它與有 N 型接頭的裝置相容。使用突波保護器將無線裝置連接到外接天線，可以保護整個網路避免災難性的電力突波。

• Wide-band operation 0-6 GHz

• Compatible with 2.4/5 GHz device

• Lightning protector for outdoor wireless application

• N-male to N-female connector type

Frequency Range	0~6GHz
Insertion Loss	2.4GHz : 0.5dB / 5GHz : 0.2dB
V.S.W.R.	< 1.5
Independence	50 ohm
Max. with Standing Current	10KA @8/20uS
Power	50W
Connector	N female - N male
備註: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
