TR-5800 5.8GHz Media Wireless AV Sender

Built-in IR remote extender Interference Free.

This 5.8GHz wireless AV sender consists of one transmitter with a RCA input and one or multiple receivers with RCA output. This device transmits vivid video and hi-fi stereo sound from a VCR TV set LD DVD VCD Satellite Receiver or cable set top box to any TV or monitor. It can also be used in conjunction with a camcorder or CCD camera and turns into a wireless security monitoring system. As to the transmission capability, the signal can go up to 400 feet clear line-of -sight and even penetrate through walls. With the built-in IR remote extender, it allows the user to remotely control the audio/video sources in the other rooms. In addition, four user selectable channels allow multiple transmitters to multiple receivers operation in the same area. All these advanced features will make your home life amazingly convenient and joyful.

5.8GHz wireless transmitter and receiver with 7 selectable channels Transmitting and receiving of crisp video and hi-fi stereo even through walls Long transmission range up to 400 feet clear line-of-sight NTSC/PAL video format available Built-in IR remote extender for extending control range of IR remotes up to 100 feet even through walls High gain Patch antenna array

Frequency Range	5725 ~ 5875 MHz
Power Output	100mW
Channel Selection	PLL Synthesizer 7CH
Video-Audio Modulation/Demodulation Type	FM-FM
Antenna Type	High gain Patch Antenna
Power On Indicator	LED, RED
Operating Frequency	433.92MHz
Built-In IR Remote Extender	YES
Transmitter Output Power	12dBm
Receiving Sensitivity	-83dBm, min
Supply Voltage	DC 9V 300mA
Dimension	122mm(L) x 118mm(W) x 47mm(H)
Weight	210g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
