TR-5886DT 5.8G AHD Outdoor wireless kit

Weatherproof enclosure with high gain antenna for outdoor wireless transmission

This wireless video transceiver is specially designed for outdoor wireless CCTV installation. Built-in high gain antenna with all-in-one compact weatherproof enclosure, providing excellent video quality transmitted without any delay. Suitable for parking lot, playground, swimming pool, ranch, farm, ...... etc.

Support AHD & Analog signals 7 Channels for selection High resolution video transmission Real time video transmission Easy to install and operate Weatherproof enclosure High gain antenna

Model	TR-5886DK
Output Power	500mW
Frequency Range	5725 ~ 5875 MHz
Channel	7-Channel Selectable
Display Mode	Digital LED Channel Display
Modulation	FM-FM
Antenna	14dBi Panel antenna
Transmitter
Power Supply	DC 12V/800mA
Dimension	250mm(L) x 185mm(W) x 60mm(H)
Weight	530g
Receiver
Power Supply	DC 9V/400mA
Dimension	250mm(L) x 185mm(W) x 60mm(H)
Weight	510g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
