CPS-101HD 2CH -TVI orAHD cameras by one cable

Adding new TVI or AHD camera without any new cable. Just one pair for 2CH cameras by existing cable.

CPS-101HD a big challenge to keep the CCTV system working in good condition. If your customer wants to add HD cameras, the difficulty is more than the beginning. By CPS-101HD, you don't need to run any new cable. Using the original cable to transmit both old camera and new HD camera is done.


  • One pair for TVI or AHD cameras by one cable

  • Both videos are excellent without interference

  • Flexible application to match the TVI, AHD & Analog cameras

  • Saving much cost of cable, labor and time

ModelCPS-101HD
Channels2 Channels
SignalsTVI, AHD & CVBS
Temperature Range-10°C~60°C
Transmitter
Video Input1.0Vp-p (75 Ω)
Power LEDGreen LED
Power Consumption0.8 W
Power RequirementsDC 9~12V / 60mA
Dimensions78 x 31 x 84 (unit : mm)
Receiver
Video Output1.0Vp-p ± 0.2Vp-p (75 ohm)
Power LEDGreen LED
Power Consumption0.9 W
Power RequirementsDC 9~12V / 70mA
Dimensions78 x 31 x 84 (unit : mm)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
