TR-1050 2.4GHz Wireless AV Sender 30 CH

Long distance video transmission with 30channels

Long Distance model of 2.4GHz audio/video sender. Transmit crystal & clear video and stereo audio signal from CCTV camera / satellite TV / digital TV set top box / DVD player. Available for any AV device and keeping it without interference. Unique frequency to avoid interference from other 2.4GHz Band.

  • 30-Channel Selectable

  • Antenna Replaceable

  • Easy Installation for CCTV System

  • Real time transmit any Audio/ Video signal

  • PAL/ NTSC Available

  • Digital LED Channel Display

  • Unique Frequencies to avoid Interference from other 2.4GHz Band

  • Made in Taiwan

Power Output1W
Frequency Range2400~2483MHz
Channel30-Channel Selectable
Display ModeDigital LED Channel Display
Video-Audio Modulation/Demodulation TypeFM-FM
Antenna TypeSMA (F)
Power Supply DC 9 ~ 12 V / 320mA
Dimension118mm(L) x 86mm(W) x 32mm(H)
Power Supply DC 9 ~ 12V / 170mA
Dimension118mm(L) x 86mm(W) x 32mm(H)

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
