CPS-401 5 cameras by one cable
Adding new camera without any new cable. Just one pair for 5 cameras by existing cable.
CPS-401 are specially designed to transmit multi-video by single coaxial cable. Using existing one or designing one route to plus new cameras, transmit long-distance and against noise without interference. 5 cameras are done by one pair of CPS-401. I believe it will be amazing to you !
|
Model | CPS-401 |
Channels | 5 Channels |
Video Signal | NTSC / PAL both available |
Temperature Range | -10°C~60°C |
Transmitter | |
Video Input | 1.0Vp-p (75 Ω) |
Power LED | Green LED |
Power Consumption | 4 W |
Power Requirements | DC9~12V / 320mA |
Dimension | 170mm(L) x 112mm(W) x 32mm(H) |
Weight | 518g |
Receiver | |
Video Output | 1.0Vp-p ± 0.2Vp-p (75 ohm) |
Power LED | Green LED |
Power Consumption | 3.2 W |
Power Requirements | DC9~12V / 240mA |
Dimension | 170mm(L) x 112mm(W) x 32mm(H) |
Weight | 516g |
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice. |
