TR-500 2.4GHz Wireless AV Sender 500mW
Economic and affordable wireless sender with high c/p value
Powerful outpur 2.4GHz wireless audio/video sender to transmit clear video and stereo audio signal for CCTV camera / satellite TV / digital TV set top box / DVD & BD player and any AV output device. Including external directional dipole antennas to transmit available range up to 600 meters (clear line of sight).
|
Model | TR-500 |
Power Output | 500mW |
Frequency Range | 2400~2483 MHz |
Channel Selection | PLL, Synthesizer, 4CH |
Video-Audio Modulation/Demodulation Type | FM-FM |
Antenna Type | SMA (F) |
Power Supply | TX:DC 9V 500mA RX:DC 9V 300mA |
Dimension | 103mm(L) x 60mm(W) x 30mm(H) |
Weight | 240g |
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice. |
