RF-1016 單軸影音傳輸組(16路)

合併訊號到一條同軸電纜,並將訊號傳至遠方

RF-1016利用RF-1000的多訊號同軸傳輸特性,將16支攝影機集中傳輸,不但節省人力與線材,更大幅減輕日後的維護成本與時間.





  • Multi-distribution for many monitors

  • Excellent quality for videos and audios

  • Easy cabling and cost effecitve

  • Save spaces, time and money

  • By existing cable is done

  • Suitable for CCTV surveillance

  • Mounted on 19" rackmount

型號RF-1016
頻道16CH
顯示LED
訊號NTSC / PAL 皆適用
記憶功能頻道記憶
電源供應AC100~230V
發射器
影像輸入1.0Vp-p
聲音輸入預加強75us
淨重6.6 公斤
尺寸490 公厘(長) x 155 公厘(寬) x 260 公厘(高)
接收器
影像輸入1Vp-p±0.2Vp-p(75 ohm)
聲音輸入0.755Vp-p±0.2Vp-p(600 ohm)
淨重10 公斤
尺寸490 公厘(長) x 155 公厘(寬) x 260 公厘(高)

備註: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
