DM-100H 數位電視接收盒

免月租費,畫質清晰,無雜訊

DM-100H 為工業級的輸位頻道接收器,工業級專用模組,採用標準機櫃式安裝設計,高穩定DVB-T數位電視接收,共同天線的最佳選擇,一勞永逸,擴充簡便,免費電視的標準配備。





  • Professional designed Module to be installed on standard 19" Rack

  • High stability in receiving Digital TV Signal to satisfy the request of MATV

  • Provide excellent quality to receive Free Digital TV

  • One-Touch to switch channel

  • Made in Taiwan

ModelDM-100H
Display ModeDigital LED Channel Display
RF Input range-6dBm~ -90dBm
Transmission standardDVB-T ( ETS300 744 )
ModulationQPSK, 16-QAM, and 64QAM
Video resolution720 X 576 (PAL)/ 720 X 480 ( NTSC)
OSD languageEnglish/ Traditional Chinese
Auto channel searchYes
Power SupplyDC 9V 400mA
尺寸161 公厘(長) x 118 公厘(寬) x 32 公厘(高)
淨重450 克

備註: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
